Waste Plastic Tyre Pyrolysis Recycle Plant Plastic Waste To Fuel Machinery With CE
Product description
With the rapid development of the plastics industry, the application of plastic products is becoming more and more extensive, but because plastics are not easy to rot and degrade, this seriously affects the ecological environment of the earth. The waste plastic pyrolysis refining equipment is not only pollution-free to the environment but also can recover energy effectively. The output product Fuel oil is widely used in industries, such as steel factories, heavy oil generators, cement factories, boiler heating, etc. Or deep process it into diesel oil with our distillation plant, color, and smell removal system, the final oil can be used in trucks, tractors, etc.
Oil rate of different kinds of raw material
| Raw materials | Oil ratio |
| PP (Microwave oven food box/yogurt bottles, ect.) | 50%-75% |
| PS(fast food boxes/instant noodle boxes) | 50%-75% |
| PE(plastic film/plastic wrap) | 50%-75% |
| Plastic cable | 80% |
| ABS(engineering plastic) | 40% |
| Leftovers of paper | Wet 15-20%,Dry 60% |
| House garbage | 35%-50% |
| Plastic bags | 50% |
| Submarine cable | 75% |
| Rubber cable | 35% |
| Sole | 30% |
| Small tires | 45%-50% |
| Big tires | 35%-40% |
Specification
| Item | Content |
| Raw materials | Waste plastic, PP ,PE, PS, ABS,PMMA,etc. |
| Output | Fuel oil , carbon black,syngas |
| Model | Reactor size | Capacity |
| HY1500*3000 | 1 T/batch |
| HY2200*5500 | 5 T/batch |
| HY2200*7500 | 7 T/batch |
| HY2600*6600 | 8 T/batch |
| HY2800*6000 | 9 T/batch |
| HY2800*6600 | 10 T/batch |
| HY2800*8000 | 15 T/batch |
| Remarks | Support customization |
| Reactor material and thickness | Q345R/Q245R/310S (Boiler plate/stainless steel) 16mm/18mm |
| Land area | 300-400㎡ (L30-40m*W10m) |
| Number of workers | 3-4 |
| Oil density and calorific value | 0.89g/cm³&44.30KJ/KG |
| Processing time and power | 10-24 hours. Averagely 15KW/h |
| Certification | CE, ISO, BV, SUV, SGS Oil Report, Emission Report, 11 patents |
Features
Safety: Alarm, auto pressure releasing device, anti backfire device, vacuum pump to ensure the machine working smoothly.
Oil-water separator: Its water sealing design ensures that oil and gas are separated and combustible gas can not return to the reactor.
Energy-saving:
The inner reactor body and outside insulation cover have good airtightness, avoiding heating loss and saving fuel.
The combustible gas that cannot be further cooled down into fuel oil will be recycled to the furnace for heating the reactor, maximizing resource utilization.
The cooling water adopts a circulating mode, which is pollution-free, no discharging, and recyclable.
High efficiency discharging: Adopt screw conveyor discharging device, discharge carbon black in sealed condition, no pollution and save labor and time.
Integrated condensing device: All of the condensing parts have been installed together before delivery from the factory, saving installation time and ensuring welding quality.
Auto feeder machine to feed raw material automatically, save labor and time.
Packing and shipping
| Packaging details | 1*40FR and 1*40HQ for 10 tons 2*40 HQ for 5 tons Weight: about 30tons All goods are packed with export standard package to make sure no damage during transportation. |
| Detail details | about 15 days after receiving deposit. |
