Mobile Type School Plastic Waste To Oil Fuel Machine Pyrolysis Plastic Price
Product description
Nowadays, with human exploitation and environmental degradation, natural energy especially oil energy is becoming less and less, on the contrary, municipal solid wastes are becoming more and more. Huayin waste plastic waste to fuel pyrolysis machine can convert the normal daily wastes like plastic bags, and rubber scraps into fuel oil, which can be used as heating fuel in many industrial fields.
Output product and usage
Fuel Oil (50%-75%)
1. Used as the heating material and sell it to cement factories, glass factories, ceramic factories, electric power factories, steel making factories, boiler factories, etc.
2. Used in heavy oil generator for electricity generation.
3. Deep process it into diesel oil with our distillation plant, color and smell removal system, the final oil can be used in diesel engines like trucks, tractors, etc.
Carbon Black (30%-35%)
Slag for construction.
Flammable Gas (8%-10%)
1. Recycled into the furnace to heat reactor instead of coal/wood/oil/natural gas.
2. Storage the extra gas to restart the next batch.
Specification
| Item | Content |
| Raw materials | Waste tyre/rubber |
| Output | 45% fuel oil, 30% carbon black, 10% steel wire, 10%-15% syngas |
| Model | Reactor size | Capacity |
| HY1500*3000 | 1 T/batch |
| HY2200*5500 | 5 T/batch |
| HY2200*7500 | 7 T/batch |
| HY2600*6600 | 8 T/batch |
| HY2800*6000 | 9 T/batch |
| HY2800*6600 | 10 T/batch |
| HY2800*8000 | 15 T/batch |
| Remarks | Support customization |
| Reactor material and thickness | Q345R/Q245R/310S (Boiler plate/stainless steel) 16mm/18mm |
| Land area | 300-400㎡ (L30-40m*W10m) |
| Number of workers | 3-4 |
| Oil density and calorific value | 0.89g/cm³&44.30KJ/KG |
| Processing time and power | 10-24 hours. Averagely 15KW/h |
| Certification | CE, ISO, BV, SUV, SGS Oil Report, Emission Report, 11 patents |
Our advantages
A. Safety. We treat safety as the first important thing in production.
1. Two devices to avoid backfire in production: oil-water separator and anti-back fire device.
2. Vacuum device makes the reactor work under ordinary pressure or negative pressure.
3. Temperature monitoring and Pressure gauge to monitor the pressure. If the pressure goes above a certain level, the bell will alarm and the safety valve will release the pressure automatically.
B. Environmental protection
Environmental protection
1. The flue gas (caused by burning fuel to heat the reactor) will be purified and cooled by a powerful ceramic packing dust removal device, then can be released into the air through the chimney.
2. Carbon black will be discharged out in sealed condition to avoid pollution.
C. Energy saving
1. The flame path is designed as a spiral so that the quantity of heat can be fully used.
2. The syngas is recycled to heating furnace for burning, thus saving your heating fuel.
3. The insulation cover is formed by 3 layers: steel plate, rock wool, and refractory cement. Excellent thermal insulation effect helps save fuel.
After-sales Service:
1. Based on customers’ requests and budgets, we help you make the most economic solutions.
2. Providing a Turnkey project.
3. Engineers are available to go overseas for plant installation, test the machine, and train workers.
4. One year warranty for the main reactor of pyrolysis machines and lifetime maintenance for complete machines.
